• Standard Duty Commercial
• Heavy Duty Residential

• 2-3/4" (70mm)
• 2-3/8" (60mm)

• ADA Compliant ANSI A117.1 Accessibility Code
• BHMA Certified ANSI A156.12, Grade 2

• 1" (25 mm) throw, brass with concealed hardened steel roller
• 1-1/8" x 2-1/4" (29 mm x 57 mm) faceplate for 2-3/4" (70 mm) backset
• 1" x 2-1/4" (25 mm x 57 mm) faceplate for 2-3/8" (65 mm) backset

• 1-3/8" - 1-3/4" (35 mm - 45 mm) - Standard
• 2"(52 mm) - Optional

• Wrought brass, bronze, and stainless steel
• Lever is zinc based, plated to match BHMA symbols

US4, US10B, US26D

Privacy with Indicator

• 1/2" (13 mm) throw, stainless steel
• 1-1/8" x 2-1/4" (29 mm x 57 mm) faceplate for 2-3/4" (70 mm) backset
• 1" x 2-1/4" (25 mm x 57 mm) faceplate for 2-3/8" (65 mm) backset

Archer, August and Withnell

Heavy gauge steel, zinc dichromated for corrosion resistance.

Non-handed

• 1-1/8" x 2-3/4" (29 mm x 70 mm) no-lip deadbolt strike - Standard
• 1-1/8" x 2-3/4" (29 mm x 70 mm) Tee Strike - Standard

Lifetime
