• Medium Duty Commercial
• Heavy Duty Residential

Adjustable 2-3/8" - 2-3/4" (60mm - 70mm)

• ADA Compliant ANSI A117.1 Accessibility Code
• UL/cUL Listed for all functions up to 3 hours "A" label single doors
• UL10C Positive Pressure Rated
• BHMA Certified ANSI A156.2, Series 4000, Grade 2

• Keyed Different - standard
• Cylinder drilled 6 pin, Keyed 5 pin - standard
• Other Keying options, including 6 pin keyed, available from factory
• Zero bit cylinders will be 6 pin keyed
• SFIC uncombinated or combinated, brass 6 pin or 7 pin cores sold separately
• Levers prepped for SFIC cores are only available in US26D and BLK finishes

1-3/8" - 1-3/4" (35 mm - 45 mm)

• Rose - Wrought brass, bronze, and stainless steel
• Lever - Zinc based, plated to match BHMA symbols

US4, US10B, US26D

Classroom (F84)

• 1/2" (13 mm) throw, stainless steel
• 1" x 2-1/4" (25 mm x 57 mm) faceplate
• Deadlocking latchbolt prevents manipulation when door is closed
• Square corner faceplate standard, round corner optional

Archer, August and Withnell

• No exposed mounting screws
• Non-handed

Split Finish

• 1-1/4" x 4-7/8" (32 mm x 124 mm) ASA strike
• Optional strikes available

Five-Year
